Fairbank Equipment, Inc. www.fairbankequipment.com L255 SPRAY TIPS & NOZZLES80%u00b0110%u00b0PSIDROPSIZECAPACITYONENOZZLEIN GPMCAPACITYONENOZZLEINOZ./MIN.20G 1 PA GALLONS PER 000 SQ. FT.110%u00ba 4 MPH 5 MPH 6 MPH 8 MPH 10 MPH 12 MPH 15 MPH 20 MPH 2 MPH 3 MPH 4 MPH 5 MPHAI80015AI110015(100)30 UC 0.13 17 9.7 7.7 6.4 4.8 3.9 3.2 2.6 1.9 0.44 0.29 0.22 0.18 40 XC 0.15 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20 50 XC 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23 60 VC 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24 70 VC 0.20 26 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 0.68 0.45 0.34 0.27 80 VC 0.21 27 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 0.71 0.48 0.36 0.29 90 C 0.23 29 17.1 13.7 11.4 8.5 6.8 5.7 4.6 3.4 0.78 0.52 0.39 0.31 100 C 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33AI8002AI11002(50)30 UC 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23 40 XC 0.20 26 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 0.68 0.45 0.34 0.27 50 XC 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 60 VC 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33 70 VC 0.26 33 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 0.88 0.59 0.44 0.35 80 VC 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38 90 VC 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41 100 C 0.32 41 24 19.0 15.8 11.9 9.5 7.9 6.3 4.8 1.1 0.73 0.54 0.44AI80025AI110025(50)30 UC 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 40 XC 0.25 32 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 0.85 0.57 0.43 0.34 50 XC 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38 60 XC 0.31 40 23 18.4 15.3 11.5 9.2 7.7 6.1 4.6 1.1 0.70 0.53 0.42 70 VC 0.33 42 25 19.6 16.3 12.3 9.8 8.2 6.5 4.9 1.1 0.75 0.56 0.45 80 VC 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48 90 VC 0.38 49 28 23 18.8 14.1 11.3 9.4 7.5 5.6 1.3 0.86 0.65 0.52 100 C 0.40 51 30 24 19.8 14.9 11.9 9.9 7.9 5.9 1.4 0.91 0.68 0.54AI8003AI11003(50)30 UC 0.26 33 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 0.88 0.59 0.44 0.35 40 XC 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41 50 XC 0.34 44 25 20 16.8 12.6 10.1 8.4 6.7 5.0 1.2 0.77 0.58 0.46 60 XC 0.37 47 27 22 18.3 13.7 11.0 9.2 7.3 5.5 1.3 0.84 0.63 0.50 70 VC 0.40 51 30 24 19.8 14.9 11.9 9.9 7.9 5.9 1.4 0.91 0.68 0.54 80 VC 0.42 54 31 25 21 15.6 12.5 10.4 8.3 6.2 1.4 0.95 0.71 0.57 90 VC 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7 1.5 1.0 0.77 0.61 100 C 0.47 60 35 28 23 17.4 14.0 11.6 9.3 7.0 1.6 1.1 0.80 0.64AI8004AI11004(50)30 UC 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48 40 XC 0.40 51 30 24 19.8 14.9 11.9 9.9 7.9 5.9 1.4 0.91 0.68 0.54 50 XC 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7 1.5 1.0 0.77 0.61 60 XC 0.49 63 36 29 24 18.2 14.6 12.1 9.7 7.3 1.7 1.1 0.83 0.67 70 VC 0.53 68 39 31 26 19.7 15.7 13.1 10.5 7.9 1.8 1.2 0.90 0.72 80 VC 0.57 73 42 34 28 21 16.9 14.1 11.3 8.5 1.9 1.3 0.97 0.78 90 VC 0.60 77 45 36 30 22 17.8 14.9 11.9 8.9 2.0 1.4 1.0 0.82 100 C 0.63 81 47 37 31 23 18.7 15.6 12.5 9.4 2.1 1.4 1.1 0.86AI8005AI11005(50)30 UC 0.43 55 32 26 21 16.0 12.8 10.6 8.5 6.4 1.5 0.97 0.73 0.58 40 XC 0.50 64 37 30 25 18.6 14.9 12.4 9.9 7.4 1.7 1.1 0.85 0.68 50 XC 0.56 72 42 33 28 21 16.6 13.9 11.1 8.3 1.9 1.3 0.95 0.76 60 XC 0.61 78 45 36 30 23 18.1 15.1 12.1 9.1 2.1 1.4 1.0 0.83 70 VC 0.66 84 49 39 33 25 19.6 16.3 13.1 9.8 2.2 1.5 1.1 0.90 80 VC 0.71 91 53 42 35 26 21 17.6 14.1 10.5 2.4 1.6 1.2 0.97 90 VC 0.75 96 56 45 37 28 22 18.6 14.9 11.1 2.6 1.7 1.3 1.0 100 VC 0.79 101 59 47 39 29 23 19.6 15.6 11.7 2.7 1.8 1.3 1.1AI8006AI11006(50)30 UC 0.52 67 39 31 26 19.3 15.4 12.9 10.3 7.7 1.8 1.2 0.88 0.71 40 UC 0.60 77 45 36 30 22 17.8 14.9 11.9 8.9 2.0 1.4 1.0 0.82 50 XC 0.67 86 50 40 33 25 19.9 16.6 13.3 9.9 2.3 1.5 1.1 0.91 60 XC 0.73 93 54 43 36 27 22 18.1 14.5 10.8 2.5 1.7 1.2 0.99 70 XC 0.79 101 59 47 39 29 23 19.6 15.6 11.7 2.7 1.8 1.3 1.1 80 VC 0.85 109 63 50 42 32 25 21 16.8 12.6 2.9 1.9 1.4 1.2 90 VC 0.90 115 67 53 45 33 27 22 17.8 13.4 3.1 2.0 1.5 1.2 100 VC 0.95 122 71 56 47 35 28 24 18.8 14.1 3.2 2.2 1.6 1.3AI11008(50)30 UC 0.69 88 51 41 34 26 20 17.1 13.7 10.2 2.3 1.6 1.2 0.94 40 UC 0.80 102 59 48 40 30 24 19.8 15.8 11.9 2.7 1.8 1.4 1.1 50 XC 0.89 114 66 53 44 33 26 22 17.6 13.2 3.0 2.0 1.5 1.2 60 XC 0.98 125 73 58 49 36 29 24 19.4 14.6 3.3 2.2 1.7 1.3 70 XC 1.06 136 79 63 52 39 31 26 21 15.7 3.6 2.4 1.8 1.4 80 VC 1.13 145 84 67 56 42 34 28 22 16.8 3.8 2.6 1.9 1.5 90 VC 1.20 154 89 71 59 45 36 30 24 17.8 4.1 2.7 2.0 1.6 100 VC 1.26 161 94 75 62 47 37 31 25 18.7 4.3 2.9 2.1 1.7203020Note:this tip is not compatible with the4193A check valve tip strainer.How to order:Specify tip number.Example: AI11004-VS %u2013 Stainless Steel withVisiFlo color-codingFeatures:Stainless steel insert produces a tapered coverage in broadcast spraying.with VisiFlo%u00ae color-coding.Larger droplets for less drift. Available in eight capacities with a recommended pressure rating 30%u2013115 PSI (2%u20138 bar).Depending on the chemical, produces of a Venturi air aspirator. Automatic spray alignment with 25598-*-NYR Quick TeeJet%u00ae capand gasket.SpacingSprayHeightCONTACTPRODUCTSYSTEMICPRODUCTDRIFTMANAGEMENTGOOD EXCELLENT EXCELLENTOptimum Spray Height Always Note: double check your application rates.Tabulations are based on spraying water at 70%u00b0F (21%u00b0C). AIR INDUCTION TIPSFeatures%u2022 Larger droplets for less drift%u2022 Stainless steel insert produces a tapered edge flat spray pattern for uniform coverage in broadcast spraying%u2022 Polymer insert holder and pre-orifice with VisiFlo%u00ae color-coding%u2022 Depending on the chemical, produces large air-filled drops through the use of a Venturi air aspirator%u2022 Available in eight capacities with a recommended pressure rating 30-115 PSI%u2022 Automatic spray alignment with 114443-*-CELR Quick TeeJet%u00ae cap and gasket (old part number: 25598-*-NYR)DescriptionAI Tip
